Precision CMM Inspection & First Article Inspection — Online Booking
AS9102-compliant inspection with 2–3 day turnaround, instant online quotes, and ITAR registration—upload your drawing, get a quote, and schedule in minutes.
CMM Inspection & FAI Services Built for Production Speed
PCDrilling provides coordinate measuring machine (CMM) inspection and first article inspection (FAI) services for manufacturers who need reliable dimensional verification without the delays of traditional metrology labs.
Dimensional CMM Inspection
Full 3D coordinate measurement of machined, molded, and fabricated components. We verify every critical dimension against your engineering drawing or CAD model — from basic length and diameter measurements to complex GD&T callouts including true position, profile, runout, and concentricity. Tolerances verified to ±0.0002”.
First Article Inspection (AS9102-Compliant FAI reports)
Complete AS9102 compliant Rev C first article inspection reports, including all three required forms: Part Number Accountability (Form 1), Product Accountability (Form 2), and Characteristic Accountability (Form 3). Delivered as a comprehensive FAIR compliant package.
Transparent & Predictable Pricing
We believe inspection pricing should be straightforward. Our rates are based on feature count — not vague hourly estimates that balloon unexpectedly.
Simple
Feature Count: 40 features
Estimated Turn-Around:
+2 business days
Starting at: $300
All quotes include a base setup fee and per-feature inspection charges.
Standard
Feature Count: 40-120 features
Estimated Turn-Around:
3-4 business days
Starting at: $500
Complex
Feature Count: 121+ features
Estimated Turn-Around:
5-7 business days
Starting at: $800
What’s Included & How it WOrks
-
Included in Every Quote
Every quote includes a base setup fee along with per-feature inspection pricing. All add-on services are clearly itemized for your approval before work begins—so you always know exactly what you’re paying for, with no hidden fees.
-
Optional Add-Ons
Additional services such as AS9102 documentation, ballooned drawings, rush delivery, and multi-setup configurations are available and can be added based on your project needs.
-
Volume Pricing
Volume discounts are available for NPI programs and repeat production runs. The more parts you inspect annually, the more cost savings you can expect.
-
Simple Payment Structure
A $250 deposit is required at booking to secure your inspection slot. The remaining balance is invoiced upon completion, with the final cost capped at your quoted price plus 10%.
No surprises. No hidden fees.
Frequently Asked Questions
-
A coordinate measuring machine (CMM) inspection uses a precision probe system to measure the physical geometry of a manufactured part. The CMM compares actual measurements against engineering drawing specifications to verify dimensional conformance. CMM inspection is the industry standard for quality verification in aerospace, defense, semiconductor, and precision manufacturing.
-
A first article inspection is a comprehensive verification process — documented per AS9102 — that confirms a newly manufactured or revised production part meets all design requirements. The FAI report package includes three standardized forms covering part identification, material/process accountability, and dimensional characteristic verification.
-
AS9102 Rev C requires three completed forms: Form 1 (Part Number Accountability), Form 2 (Product Accountability — covering materials and special processes), and Form 3 (Characteristic Accountability — covering every measurable dimension and tolerance). The standard applies to aerospace, space, and defense supply chain manufacturers.
-
Our Sprint 300 CMM is calibrated to NIST-traceable standards and verified to tolerances of ±0.0002” (0.005 mm). Calibration is current through September 18, 2026.
-
Yes. PCDrilling is ITAR registered. We maintain security protocols for handling controlled technical data, CUI, and export-controlled engineering drawings.
-
Standard turnaround is 2–7 business days depending on complexity. Rush options are available at 48 hour and 24-hour delivery for qualifying inspections.
-
Select your inspection parameters, choose add-on services, review your quote, and pay a $250 deposit to secure your inspection slot. Ship your part to us, and we begin inspection within one business day of receipt. Your report is delivered electronically upon completion, and the remaining balance is invoiced (capped at your quote +10%).
-
We accept PDF drawings, STEP files, IGES files, and native CAD formats (SolidWorks, AutoCAD, Fusion 360, Mastercam). Ballooned PDFs preferred but not required — we offer ballooning as an add-on service.
-
Yes. We offer tiered discounts for NPI programs and repeat production customers based on annual part volume. Discounts range from 10% to 40% depending on volume.
